Open-Source Simulation Ecososystems for Digital, System-Level, and Electrical & Electronic Circuit Design: A Comprehensive Research White Paper
Executive Summary
Simulation is a cornerstone of modern electrical, electronic, and computer engineering. It enables engineers and researchers to explore design alternatives, validate system behavior, reduce prototyping costs, and accelerate innovation cycles. Traditionally, simulation-heavy workflows have relied on expensive proprietary tools, creating significant barriers for small and medium enterprises (SMEs), startups, universities, and publicly funded research organizations. Over the past two decades, however, open-source simulation ecosystems have matured across digital, analog, mixed-signal, and system-level domains.
This research white paper presents a comprehensive 3,000-word survey of open-source simulators spanning:
- Digital hardware description languages (Verilog, SystemVerilog, VHDL)
- SystemC and Transaction-Level Modeling (TLM)
- Analog and mixed-signal (AMS) simulation
- Electrical and electronic circuit simulation (SPICE-class, power electronics)
- Electromagnetic (EM) and multiphysics modeling
- Integrated multi-domain simulation workflows
The paper also highlights how IAS-Research.com can help organizations design, integrate, validate, and operationalize these tools into robust, scalable engineering and research workflows. The focus is on practical adoption, research credibility, and strategic value creation rather than tool listings alone.
1. Introduction
Engineering simulation is no longer a luxury; it is a necessity across industries such as semiconductors, power systems, automotive electronics, aerospace, renewable energy, telecommunications, and industrial automation. Simulation allows teams to analyze complex systems before physical implementation, reducing cost, time-to-market, and technical risk.
Electrical and electronic systems today are inherently multi-domain:
- Digital logic interacts with analog front ends
- Power electronics interface with control algorithms
- Embedded software runs on complex system-on-chip (SoC) platforms
- Physical effects such as thermal and electromagnetic coupling influence performance and reliability
As system complexity increases, so does the need for hierarchical simulation, spanning transistor-level accuracy to system-level abstraction. Open-source simulation tools have evolved to support this spectrum, offering transparency, flexibility, and long-term sustainability.
For SMEs and research institutions, open-source simulators offer additional benefits:
- Elimination of high licensing costs
- Reduced vendor lock-in
- Reproducible research environments
- Customization for domain-specific needs
This white paper examines how these tools can be combined into cohesive simulation ecosystems and how expert support from IAS-Research.com enables their effective adoption.
2. Digital HDL Simulation (Verilog, SystemVerilog, VHDL)
2.1 Role of HDL Simulation in Modern Design
Hardware Description Languages (HDLs) remain central to digital system design. RTL simulation is essential for functional verification, performance estimation, and early software integration. While commercial simulators dominate high-end ASIC flows, open-source HDL simulators are widely used in:
- FPGA development
- RISC-V processor design
- Academic research
- Early-stage ASIC prototyping
2.2 Verilog and SystemVerilog Simulators
Verilator has emerged as the most impactful open-source Verilog/SystemVerilog simulator. Rather than traditional event-driven simulation, Verilator translates RTL into optimized C++ or SystemC models, enabling extremely high simulation speeds.
Key strengths include:
- Cycle-accurate simulation
- Scalability to millions of gates
- Tight integration with C++, SystemC, and Python-based verification
- Strong industry adoption in open hardware communities
Typical workflow:
SystemVerilog RTL → Verilator → C++ / SystemC model → Software-driven testbench
Icarus Verilog (iverilog) complements Verilator by providing an event-driven simulation model closer to traditional HDL simulators. It is widely used for education, smaller designs, and quick functional checks.
Together, Verilator and Icarus Verilog form a practical open-source foundation for digital design verification.
2.3 VHDL Simulation
VHDL remains dominant in aerospace, defense, rail, and industrial control systems. The open-source ecosystem here is anchored by GHDL, a mature VHDL simulator supporting VHDL-2008 and partial VHDL-2019 standards.
GHDL provides:
- Multiple backends (GCC, LLVM)
- Waveform generation (VCD, FST, GHW)
- Interfaces for co-simulation (VPI, VHPI, VHPIDIRECT)
NVC, a newer VHDL compiler/simulator, offers an alternative with a modern codebase and cross-platform support.
These tools are essential for organizations maintaining legacy VHDL IP while adopting modern verification practices.
3. SystemC, Transaction-Level Modeling (TLM), and Hardware–Software Co-Design Simulation
3.1 Motivation for System-Level and HW/SW Co-Design Simulation
As systems evolve into complex cyber-physical platforms, the boundary between hardware and software has become increasingly blurred. Modern products—such as SoCs, embedded AI platforms, automotive ECUs, smart grid controllers, and industrial IoT devices—require simultaneous development of hardware and software. Traditional sequential workflows (hardware first, software later) introduce delays, integration risks, and costly redesigns.
Hardware–software (HW/SW) co-design simulation enables:
- Early software development before silicon availability
- Architectural trade-off analysis (performance, power, latency)
- Validation of hardware–software interfaces
- Faster system integration and reduced time-to-market
3.2 SystemC Framework as the Foundation for Co-Design
SystemC (IEEE 1666) is the foundational open standard for HW/SW co-design simulation. Built as a C++ class library with a discrete-event simulation kernel, SystemC enables modeling across multiple abstraction levels:
- Cycle-accurate RTL-style models
- Loosely timed (LT) and approximately timed (AT) TLM models
- Functional and architectural models for software execution
SystemC allows engineers to execute embedded software binaries against abstract or partially accurate hardware models, making it central to virtual prototyping and co-design.
3.3 Transaction-Level Modeling (TLM-2.0)
TLM-2.0 provides standardized interfaces for modeling communication between system components at a higher level of abstraction than RTL. Key benefits include:
- Faster simulation speeds
- Early system-level validation
- Separation of computation and communication concerns
TLM models are widely used to represent:
- On-chip interconnects (AMBA, NoC)
- Memory subsystems
- Peripheral interfaces
3.4 Verilator + SystemC for HW/SW Co-Simulation
A dominant open-source HW/SW co-design workflow combines:
- Verilator for cycle-accurate simulation of RTL hardware blocks
- SystemC/TLM for system integration and testbench modeling
- C/C++ or embedded Linux software running against the simulated hardware
Typical workflow:
RTL (Verilog/SystemVerilog) → Verilator → SystemC wrapper ↳ Embedded software / OS
This approach enables realistic validation of:
- Processor cores (e.g., RISC-V)
- Memory hierarchies
- Device drivers and firmware
3.5 Instruction Set Simulators and Virtual Platforms
HW/SW co-design often incorporates instruction set simulators (ISS) to execute software efficiently while maintaining architectural accuracy. Common open-source examples include:
- QEMU – Dynamic binary translation-based emulator widely used for embedded Linux and SoC prototyping
- gem5 – Detailed architectural simulator for CPU, memory, and system research
These simulators are frequently integrated with SystemC-based environments to create hybrid virtual platforms that balance speed and accuracy.
3.6 Hybrid Co-Design Workflows
Practical open-source HW/SW co-design environments often combine multiple simulators:
- QEMU or gem5 for fast software execution
- SystemC/TLM for system-level hardware modeling
- Verilator for selected RTL blocks requiring cycle accuracy
Such hybrid platforms support:
- Early firmware and OS bring-up
- Performance bottleneck analysis
- Exploration of accelerator-based architectures
3.7 Role of HW/SW Co-Design in Research and Industry
HW/SW co-design simulation is essential in:
- RISC-V processor development
- AI and ML accelerator integration
- Automotive and aerospace embedded systems
- Smart grid and power electronics controllers
Open-source co-design simulators lower the barrier to entry for SMEs and research institutions, enabling innovation without prohibitive licensing costs.
4. Analog and Mixed-Signal (AMS) Simulation
4.1 Importance of AMS Simulation
Modern electronic systems rarely consist of purely digital logic. Sensors, power management circuits, RF interfaces, and analog front ends interact closely with digital processing. Accurate modeling of these interactions is critical for system reliability and performance.
4.2 SystemC AMS (IEEE 1666.1)
The SystemC-AMS Proof-of-Concept library extends SystemC to support analog and mixed-signal modeling. It introduces:
- Timed Data Flow (TDF) models for signal processing
- Electrical Linear Networks (ELN) for analog behavior
SystemC-AMS is well suited for:
- RF and communication system modeling
- Control systems
- Power electronics average models
- Sensor-to-digital interaction studies
It enables faster simulation than transistor-level SPICE while maintaining sufficient fidelity at the system level.
4.3 Mixed-Signal Co-Simulation Approaches
Open-source mixed-signal workflows typically combine:
- HDL simulators for digital logic
- SPICE-class simulators for analog circuits
- SystemC/SystemC-AMS for system integration
These approaches are increasingly relevant for IoT devices, automotive electronics, and energy systems.
5. Electrical and Electronic Circuit Simulation
5.1 SPICE-Class Circuit Simulators
SPICE-based simulation remains the gold standard for analog and circuit-level accuracy. The leading open-source option is ngspice, which supports:
- Transistor-level simulation
- Behavioral modeling
- Noise and AC analysis
- Co-simulation with digital logic
Xyce, developed for high-performance computing environments, provides parallel SPICE-compatible simulation suitable for very large circuits and research-scale problems.
Applications include:
- Analog IC and PCB design
- Power electronics
- Sensor interfaces
- Reliability and corner-case analysis
5.2 Power Electronics and Control Modeling
Power electronics introduces additional challenges, including switching behavior, control loops, and multi-domain coupling. Open-source tools used in this space include:
- QUCS / QUCS-S for schematic-based circuit simulation
- OpenModelica for equation-based multi-domain modeling
- Scilab + Xcos for control systems and power converter modeling
These tools are widely used in academia and increasingly adopted in industrial R&D.
5.3 Electromagnetic and Multiphysics Simulation
While fewer fully open-source EM tools exist, several mature projects support electromagnetic and multiphysics analysis:
- OpenEMS for FDTD-based EM simulation
- Elmer FEM for electromagnetic, thermal, and structural analysis
Such tools are critical for antenna design, EMC/EMI studies, and high-voltage equipment research.
6. Integrated Multi-Domain Simulation Workflows
6.1 Need for Integration
Modern products require simultaneous consideration of:
- Digital logic and embedded software
- Analog and power electronics
- Control algorithms
- Physical effects such as thermal and EM coupling
Isolated simulation is no longer sufficient. Open-source ecosystems enable integrated, multi-domain simulation through standardized interfaces and scripting.
6.2 Typical Open-Source Workflows
Representative workflows include:
- Verilator + SystemC + SystemC-AMS for SoC and mixed-signal systems
- ngspice + HDL co-simulation for analog–digital interaction
- Python-driven verification using cocotb, PySpice, and custom scripts
These workflows support agile development, continuous integration, and reproducible research.
7. Challenges and Limitations of Open-Source Simulation
Despite significant progress, open-source simulators face challenges:
- Fragmented documentation and learning resources
- Integration complexity across domains
- Limited availability of certified component models
- Higher reliance on in-house expertise
Overcoming these challenges requires structured methodologies, validation processes, and experienced system architects.
8. How IAS-Research.com Can Help
IAS-Research.com specializes in bridging the gap between open-source simulation tools and real-world engineering, research, and business outcomes.
8.1 Simulation Architecture and Toolchain Design
- Selection of appropriate simulators across digital, analog, and system levels
- Definition of scalable, reproducible simulation workflows
- Integration of HDL, SPICE, SystemC, and control models
8.2 Electrical and Electronic Systems Research
- Power electronics and HVDC modeling
- Analog and mixed-signal system analysis
- Embedded systems and SoC architecture studies
8.3 Validation, Documentation, and Knowledge Transfer
- Research-grade documentation and white papers
- Support for grants, proposals, and academic publications
- Training and mentoring for engineering teams
8.4 SME and Academic Enablement
- Cost-effective alternatives to commercial EDA tools
- Long-term maintainability and transparency
- Alignment of simulation strategy with business and research objectives
By combining deep engineering expertise, systems thinking, and applied research, IAS-Research.com enables organizations to adopt open-source simulation with confidence and strategic clarity.
9. Conclusion
Open-source simulators now span the full spectrum of electrical, electronic, and digital system design—from transistor-level circuits to system-level virtual platforms. When properly integrated, these tools offer powerful, transparent, and cost-efficient alternatives to proprietary solutions.
For SMEs, universities, and research organizations, open-source simulation is not merely a cost-saving measure; it is a strategic enabler of innovation, reproducibility, and long-term independence. With expert guidance and structured workflows, organizations can leverage these ecosystems to accelerate development and reduce risk.
IAS-Research.com plays a critical role in enabling this transformation by providing research-driven integration, validation, and strategic support across the full simulation stack.
Keywords
Open-source simulation, Verilog, VHDL, SystemC, SystemC AMS, ngspice, power electronics, electromagnetic simulation, mixed-signal design, multi-domain modeling, hardware–software co-design, IAS-Research
References
- Accellera Systems Initiative, IEEE 1666™ SystemC Language Reference Manual, Accellera, 2023.
- Accellera Systems Initiative, IEEE 1666.1™ SystemC Analog/Mixed-Signal Extensions, Accellera, 2022.
- D. C. Black, J. Donovan, B. Bunton, and A. Keist, SystemC: From the Ground Up, 2nd ed., Springer, 2010.
- S. Abdi et al., “Transaction-Level Modeling in SystemC,” IEEE Design & Test of Computers, vol. 24, no. 1, pp. 46–55, 2007.
- W. Snyder, “Verilator: Fast and Accurate Verilog/SystemVerilog Simulation,” Open Hardware Conference Proceedings, 2021.
- Icarus Verilog Contributors, Icarus Verilog User Guide and Reference, Open Source Documentation, 2024.
- T. Gingold et al., “GHDL: Free and Open-Source VHDL Simulator,” Journal of Open Source Software, vol. 4, no. 43, 2019.
- M. Thompson, Digital Design and Computer Architecture, 2nd ed., Morgan Kaufmann, 2013.
- P. J. Ashenden, The Designer’s Guide to VHDL, 3rd ed., Morgan Kaufmann, 2008.
- QEMU Project, QEMU Emulator Documentation, Open Source Virtualization Project, 2024.
- N. Binkert et al., “The gem5 Simulator,” ACM SIGARCH Computer Architecture News, vol. 39, no. 2, pp. 1–7, 2011.
- UNISIM Consortium, UNISIM: A System Simulator for Virtual Platforms, CEA Research Documentation, 2022.
- P. Kundert et al., The Designer’s Guide to SPICE and Spectre, Kluwer Academic Publishers, 1995.
- ngspice Contributors, ngspice User’s Manual, Open Source Documentation, 2024.
- E. Keiter et al., “Xyce Parallel Electronic Simulator,” Sandia National Laboratories Technical Report, 2019.
- A. Brambilla et al., “SystemC-AMS: Mixed-Signal Modeling and Simulation,” IEEE Transactions on Computer-Aided Design, vol. 29, no. 8, pp. 1256–1269, 2010.
- F. Casella et al., “Modelica and OpenModelica for Modeling and Simulation of Complex Physical Systems,” Simulation Modelling Practice and Theory, vol. 18, no. 9, pp. 1385–1399, 2010.
- Scilab Enterprises, Scilab and Xcos Documentation, Open Source Scientific Computing Platform, 2023.
- T. Weiland et al., “OpenEMS – An Open Source FDTD Solver,” IEEE International Symposium on Antennas and Propagation, 2010.
- Elmer FEM Project, Elmer Multiphysical Simulation Software Documentation, CSC – IT Center for Science, 2023.
- D. A. Patterson and J. L. Hennessy, Computer Organization and Design: The Hardware/Software Interface, 6th ed., Morgan Kaufmann, 2021.
- R. G. Sargent, “Verification and Validation of Simulation Models,” Journal of Simulation, vol. 7, no. 1, pp. 12–24, 2013.
- I. Sommerville, Software Engineering, 10th ed., Pearson, 2015.
- J. W. McCormick, “Virtual Prototyping for Embedded Systems,” IEEE Embedded Systems Letters, vol. 8, no. 2, pp. 41–44, 2016.
- IAS-Research, Applied Research and Engineering Systems Integration Methodologies, IAS-Research.com White Paper Series, 2024.
